Bearing packing machine

Project Information

A bearing packing machine is designed to efficiently package bearings and axletrees with precision and consistency. Its advanced automation and customization capabilities make it ideal for industries such as automotive, aerospace, and manufacturing, where reliable and efficient packaging is critical.

Key Features

Conveyor-fed automated handling cuts manual intervention and speeds throughput
PLC-driven control delivers precise, consistent, high-speed operation
ID-based positioning ensures pinpoint accuracy for wrapping and labeling
Switchable manual/auto modes adapt seamlessly to any production requirement

Get Free Quote Now

Manual or semi-auto wrapping of large bearings and axletrees demands heavy labor, risks uneven protection, and drives up waste. Wuxi BuHui’s FPB-400 Bearing Wrapping Machine automates handling, positioning, and wrapping—so one operator delivers consistent, high-quality packaging.

The Challenge: Packaging Large Bearings Efficiently

Labor-Intensive Handling: Heavy parts require multiple operators and create ergonomic risks.
Uneven Wraps: Lack of precise centering and tension control leads to loose or over-tight wraps.
Material Waste: Inaccurate overlap and cut-off cause excess film or paper usage.
Flow Disruptions: Manual transfer between stations stalls production.
Slow Changeovers: Varying bearing sizes demand lengthy manual adjustments.
Downtime Risks: No auto fault detection delays maintenance response.
Safety Hazards: Handling heavy bearings without reliable conveyors and guards risks accidents.

The Solution: Features & Benefits

Feature	Benefit & ROI
Automated Conveyors	Feeds and transfers 100–500 kg bearings—cuts manual labor and speeds throughput.
PLC-Controlled Operation	Stores six wrap programs and runs cycles with precision and repeatability.
Centralized & ID-Based Positioning	Automatically centers each bearing using ID systems—ensures uniform, damage-free wraps.
Adjustable Tension & Overlap	Tune wrap tightness (20–90%) and overlap for secure protection and minimal waste.
Material Versatility	Works with film, paper, woven belt, PVC, and more—match protection to your needs.
Flexible Modes	Run in manual or full automatic—adapts to varying production requirements.
Durable Construction & Safety	Heavy-duty frame, CE guards, and E-stop ensure safe, reliable operation.

Technical Specifications

Parameter	Specification
Model	FPB-400 Bearing Wrapping Machine
ID Range	300–800 mm
OD Range	500–1200 mm
Width	100–400 mm
Weight	100–500 kg
Power	AC 380 V, 50 Hz, 3-phase
Speed	30–50 sec/wrap (30–70 RPM ring)
Overlap	20%–90%
Programs	Up to 6 in PLC
Materials	Film, paper, woven/knit belt, PVC, etc.
Safety	Guardrails, interlocks, emergency stop

Ideal Applications & Industries

Bearing Plants: Automate end-of-line wrapping for heavy bearings with one operator.
OEMs & Machinery Producers: Secure packaging of large bearings for safe transport and storage.
Contract Packaging: Handle varied sizes and materials with minimal manual handling.
Logistics & Warehousing: Streamline dispatch with uniform, protective wraps.

Request Your Customized FPB-400 Solution

Contact Wuxi BuHui with your bearing specs to configure a turnkey wrapping system that boosts throughput, cuts labor, and protects your products.

A bearing packing machine streamlines the packaging of bearings by utilizing automated systems for accuracy and speed. It effectively handles various sizes and types, providing secure packaging that protects against damage during transit. This machine is essential for manufacturing operations aiming to improve efficiency and reduce packaging costs while maintaining quality.
