Hose Coil wrapping machinery FPH-500

Project Information

The FPH-500 is a vertical hose coil winding and packaging machine, ideal for large rubber hose coils, hydraulic hoses, corrugated pipes, and similar products. It ensures efficient, safe, and high-quality packaging for streamlined transportation and handling.

Key Features:

Universal Compatibility
Flexible Operation Modes & Speed
Fast, Precise Packaging (25–45 s)
Smart Touchscreen with 99 Presets

Get Free Quote Now

Protect hose, pipe, and tubing coils from moisture, dust, and damage in storage and transit. The FPH-500W Hose & Pipe Coil Wrapping Machine by Wuxi BuHui delivers reliable vertical-eye wrapping for coils of all sizes in one system. Customize overlap, adjust tension, and choose your wrapping material to streamline packaging and cut waste. Safety features and smooth operation safeguard coils and operators. Efficient load/unload design speeds up throughput. Improve consistency, reduce damage claims, and boost line efficiency with Wuxi BuHui’s FPH-500W.

The Challenge: Overcoming Key Coil Packaging Issues

Shield from the Elements: Prevent moisture and dust from degrading hoses and tubing.
One Machine, Many Sizes: Handle IDs Φ300–Φ800 mm, ODs Φ600–Φ1400 mm, widths 150–400 mm, and weights 20–200 kg without changeovers.
Faster Load/Unload: Reduce labor time and ergonomic strain when placing heavy coils.
Uniform Wrap Quality: Maintain consistent overlap and tension to avoid loose wraps and film waste.
High Throughput: Achieve cycle times of 20–30 seconds per package to meet production targets.
Safe, Smooth Operation: Eliminate sudden stops and coil shifts that risk safety and workflow.
Built-In Flexibility: Switch instantly between manual and automatic modes to suit any run.
Tailored to You: Adapt machine layout and settings to your facility and coil specs.

The Solution: Features & Benefits of the FPH-500W

Feature	Benefit & ROI
Vertical-Eye Wrapping Design	Ensures full-circumference coverage and stable loads for all coil types.
Multiple Material Compatibility	Use stretch film, HDPE, woven fabrics, or paper to balance protection and cost.
Adjustable Overlap (10%–90%)	Optimize wrap density to minimize waste and lower packaging spend.
Tension & Friction Control	Keep wraps snug to prevent deformation and ensure secure bundling.
Frequency Converter Speed Regulation	Match cycle time (28–40 sec) to your line speed for peak efficiency.
Manual/Automatic Modes	Operate manually for special jobs or automate high-volume runs with ease.
Smooth Start/Stop & Braking	Protect coil surfaces and extend machine life by reducing jams.
Safety Guardrails	Shield operators and coils from accidental contact for uninterrupted operation.
Easy Load/Unload Design	Simplify handling of bulky coils to cut labor and boost throughput.
20–30 Sec Packaging Speed	Keep up with demanding production rates and eliminate end-of-line delays.
Custom Configurations	Tailor dimensions, controls, and material handling to your exact requirements.

Technical Specifications

Parameter	Specification
Model	FPH-500W
Coil ID Range	Φ300–Φ800 mm
Coil OD Range	Φ600–Φ1400 mm
Coil Width Range	150–400 mm
Coil Weight Range	20–200 kg
Wrap Speed	28–40 sec/package
Max Ring Speed	100 RPM
Power Supply	380 V, 60 Hz, 3-phase
Power Consumption	3.5 kW
Packing Material Sizes	Film: OD 100–140 mm, ID 50 mm, W 90 mm; Paper: OD 200–450 mm, ID 50 mm, W 90 mm
Control Options	Manual/auto modes; frequency-converter; reset reduction
Tension & Braking	Adjustable tension; friction & brake controls
Safety	Guardrails; smooth braking; stable operation
Customization	Available per client specifications

Ideal Applications & Industries

Rubber Hose Manufacturers: Secure hydraulic and pneumatic hose coils from environmental damage.
Pipe & Tubing Producers: Protect plastic and rubber pipe coils in transit and storage.
OEMs: Package coiled components before assembly to maintain quality.
3PL Packaging Services: Offer flexible wrapping for diverse client needs.
Logistics & Warehousing: Stabilize pallet loads and cut damage claims.
Equipment Suppliers: Enhance end-of-line packaging in integrated systems.

Why Wuxi BuHui

Wuxi BuHui’s FPH-500W combines versatile vertical-eye wrapping, adjustable overlap, and precise tension control to minimize waste and prevent deformation. Frequency-converter speed regulation and mode switching deliver optimal throughput and flexibility. Safety guardrails, smooth braking, and a reset reduction system protect both operators and coils. Broad material compatibility and customizable design make Wuxi BuHui the partner of choice for reliable, efficient coil packaging solutions.

Request a Quote

Contact Wuxi BuHui with your coil dimensions and production requirements. We’ll tailor the FPH-500W configuration to deliver a high-throughput, protective wrapping solution that lowers total packaging costs.

The FPH-500 Hose Coil Wrapping Machine provides streamlined wrapping for hose coils, ensuring consistent protection and stability. With advanced automation and easy operation, it minimizes manual effort while enhancing packaging efficiency. Built for durability, the FPH-500 is an optimal choice for industries prioritizing secure and effective hose packaging solutions.
